| Alignment method | 6 motors core to core alignment |
| Applicable fiber | SM(G.652), MM(G.651), DS(G.653), NZDS(G.655), BIF(G.657) |
| Cladding diameter | 80-150μm |
| Coating diameter | 160-3000μm |
| Cleaved length | 5-16mm ( coating diameter<250um) |
| 16mm (coating diameter:250-1000um) | |
| Typical splice loss | SM: 0.02dB；MM: 0.01dB；DS/NZDS/BIF: 0.04dB |
| Return loss | >60dB |
| Splicing program | 40 groups |
| Operation mode | Manual/ Automatic |
| Auto-heating | Available |
| Typical splice time | 6 seconds |
| Typical heating time | 18 seconds for 60mm and 40mm shrinkable sleeves |
| Fiber magnification | 250X(X or Y view), 125X(X and Y view) |
| Viewing display | Dual high sensitivity camera, 5 inch 800*480 LCD Touch Screen Monitor |
| Data storage | 4000 groups data records |
| Loss evaluation | Available |
| Tension test | 1.8~2.25N |
| Interface | GUI menu interface, easy for operation |
| Battery capacity | 5200mAh Li-battery, 250 cycles splicing and heating |
| Power supply | Adaptor, input: AC100-240V(50/60HZ),output: DC11-13.5V |
| Electrode life | More than 4000 ARC discharges, easy to replace |
| Data storage | Pluggable 8GB micro SD card |
| Terminals | USB 2.0 port, for software upgrading, records exporting |
| Operating | Altitude:0-5000m, Humidity:0-95%,Temperature:-10~+50℃; Wind:max 15m/s |
| Dimension/Weight | 156mm(L)×141mm(W)×156mm(H) / 2.45kg (including battery) |
